SPECIFICHE MECCANICHE
Telaio: Alu. 700c, integrated battery, integrated HT, disc brake, internal cables
Forcella: Suntour NEX 700c, alu with alu crown, 50mm o Zoom 187D, 29”, 65mm, Coil
Serie sterzo: FSA integrated 1”1/8
Guarnitura: Byte alu 42T cartridge
Cambio: Shimano Altus RD-M310
Comandi: Hydraulic disk, Rotor 160 mm, with brake lever switch
Freni: Shimano SL-M315 PushPull, 8s
Ruota Libera: DNP 8s 13-28
Pedali: Resin antislip
Mozzi: Shimano quick release front, motor on rear, 36h, INT
Cerchi: Beretta 700c, double wall w/eylets, 36h, disc
Attacco manubrio: Byte alu over, ahead, adjustable
Piega manubrio: Byte alu over
Reggisella: Byte alu with clamp, 27,2mm
Sella: Selle Royal Lancia
Coperture: Byte Trento 700x45c, with reflecting line
Parafanghi: Single stay speedy
Copricatena: Plastic, L type
Portapacchi: Rear alu 14mm with spring, 25kg load
Luci: esterne Axa front (15 lux) and rear LED, controlled by display
Taglia: 45
Colore: Flat Grey/Blue Navy
Note: kickstand Ursus adjustable, bell

SPECIFICHE ELETTRICHE
Coppia massima: 45 Nm
Tipo sensore: Speed sensor w/12 pulses
Batteria: 504Wh
Tipo caricabatteria:2A Europlug
Tempo di ricarica: 100%: 8h16 / 80%: 6h16m
Velocità max assistita: 25km/h
Display: Atala A10 LCD Smart CAN, with remote control
Potenza: 5 levels, Speed/Torque adjust
Altre funzioni: Soft start: 0 - 6km/h, with no pedalingExternal light controlSpeed informationBattery information
