FRAME: Aluminum, 700C, Hydroformed, Easy Access, Integrated Battery, Tapered,
Internal Cable Routing, QR
FORK: Zoom 188D, Spring, Lockout, 65mm Travel, QR, 32mm Stanchions
CHAIN COVER: FSA Bashguard
HEADSET: FSA CRII Dual, 1.5”, Internal Cable Routing
CRANKSET: FSA CK-745 // CK-320, 38T with Bashguard
REAR DERAILLEUR: Shimano Deore RD-M4120, Shadow Plus, 10 Speed
SHIFT LEVERS: Shimano Deore SL-M6100-R Rapidfire-Plus, 10 Speed
BRAKES: Clarks M2, SM-RT10 Rotor 180mm/180mm
CASSETTE: Shimano CS-M4100, 10 Speed, 11/42
PEDALS: TKK Aluminum
FRONT HUB: Shimano QC300, CL, 32 holes
REAR HUB: Shimano QC300, CL, HG, 32h
RADIALE E25 RIMS: eBike Ready, Tubeless Ready, 584x25c
HANDLEBAR STEM: Alu, Ahead, Adjustable, 25.4mm
HANDLEBAR: Alu, 640mm, Barbore 31.8mm, Rise 25mm, Back sweep 25°
SEATPOST: Alu, 31.6mm
SADDLE: Selle Royal Vivo Unitec
TIRES: Schwalbe Marathon Efficiency, 27.5″x2.15″
MUDGUARDS: SKS A60S
MOTOR: OLI Edge, 36 V, 250 W
MAX TORQUE: 90 Nm
MAX POWER: 750 W
SENSOR TYPE: Torque
BATTERY: Phylion IT31L 800Wh, weight 3.9 kg
CHARGER TYPE: 4 A
CHARGING TIME: Up to 6.9 hours
MAX ASSISTED SPEED: 25 km/h
DISPLAY: OLI High Vision
POWER: Mode 1: 120% / Mode 2: 180% / Mode 3:
230% dynamic / Mode 4: 400% dynamic
LUGGAGE RACK: Aluminum, with brackets, load 25 kg
LIGHTS: Front: Axa NXT 45 – 45Lux Rear: Axa Juno
