DESIGNED FOR
Experienced pilots and those starting their racing career

FRAME KIT
Sprint carbon monocoque frame, mechanical/electronic, BB-PressFit 86.5x41, 1.4"-1.5" head tube, integrated seat clamp, full carbon dropout, flat mount disc brake, 12 x 142 thru axle, sizes 47-50-53-55-57-59-61cm
FORK
Full Carbon Aero Road 1.4">1.5" integrated head, flat mount disc brake, 12x100 thru axle
HEADSET
ACROS & FSA, integrated cable routing
COMMANDS
Shimano 105 with hydraulic disc brakes, 160mm rotors
EDIT
Shimano 105 12v, max 36T
DERAILLEUR
Shimano 105 12sp, 50-54T chainrings, 16T capacity, for 12 speeds
CRANKSET
Shimano 105 12v, 12-speed, crank length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm
BOTTOM MOVEMENT
Shimano, SM-BB72-41B, Press-fit Road, Bearing, Inner Cover
CHAIN
Shimano
BRAKES
Shimano, Hydraulic disc brake, included in the gear change
DISCS
Shimano SM-RT70 Center Lock Disc Brake Rotors, 160mm
WHEELS
Velomann alloy, disc brake, 30mm rim profile, team TC j-bend hub, 2mm round spokes, black, 622x19C clincher, w/ perimeter tape, front HH12 - rear HH12/142
TIRES
Vittoria Rubino IV G2.0 Graphene, 700x25, 60TPI
HANDLEBAR STEM
Velomann, 6061 Alloy, Rise - 7°, Oversize, 1 1/8", Ext: 80mm-44cm, 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59/61cm
FOLD
Velomann Compact, Flat Top, 6061 alloy diam. 31.8mm, 80mm reach, 130mm drop, Sizes: 400mm-44/53cm, 420mm-55/59cm, 440mm-61cm
TAPE
Bianchi ribbon, black color
SEATPOST
Velomann Alloy, Alloy Head, 15mm Offset, 27.2mm, Length: 300mm-44cm ; 350mm-47/61cm
SADDLE
Velomann Seta
